Product
Relay interface module
38 relay interface module
  • 38 relay interface module

38 relay interface module

繼電器接口模塊 (EMR或SSR)0.1 2-6-8

Relay interface module

? 6.2mm or 14mm wide

? DC or AC / DC coil version

? special coil / input leakage current suppression model

? timer interface module

? screw & screwless terminal

全國免費咨詢熱線:0755-84552800


Specifications
38.51/61 38.51.3/38.61.3
Contact specifications
Contact configuration 1 CO (SPDT) 1 CO (SPDT)
Rated current / maximum peak current a 6/10 6/10
Rated voltage / maximum switching voltage V AC 250/400 250/400
Rated load AC1 VA one thousand and five hundred one thousand and five hundred
Rated load ac15 (230 V AC) VA three hundred three hundred
Single phase motor rating (230 V AC) kw zero point one eight five zero point one eight five
Breaking capacity dc1:30/110/220 V A 6/0.2/0.12 6/0.2/0.12 6/0.2/0.12 6/0.2/0.12
Minimum switching load MW (v/ma) 500 (12/10) 500 (12/10)
Standard contact material AgNi AgNi
Coil specification
Nominal voltage (UN) V AC/DC 12 - 24 - 48 - 60 - (110…125) -  (220…240)** (110…125)
V AC (230…240)* (230…240)
V DC 6 - 12 - 24 - 48 - 60 (non polarized)
Rated power ac/dc VA (50 Hz) /w Please refer to page 9 of PDF download
1/1 0.5/—
Operating range AC/DC (0.8…1.1)UN (94…138)V —
AC (184…264)V (184…264)V
DC (0.8…1.2)UN
Holding voltage ac/dc 0.6 UN / 0.6 UN 0.6 UN / 0.6 UN
Required voltage ac/dc 0.1 UN / 0.05 UN 44 V 72 V
