Product
PCB Relay
43 compact PCB Relay
  • 43 compact PCB Relay

43 compact PCB Relay

小巧型P.C.B.繼電器(10 - 16A)

Compact PCB Relay

? small size, 15.4mm height

? sensitive DC coil: 250MW or 400MW

? extremely high coil contact isolation 10mm, 6 kV (1.2/50 μ s)

? anti flux penetration: standard is RT II, (RT III option)

? 3.2mm or 5mm pin spacing

全國免費咨詢熱線:0755-84552800


model forty-three point four one 43.41-0300 43.61-0300
Contact specifications
Contact configuration 1 CO (SPDT) 1 no (SPST-NO) 1 no (SPST-NO)
Rated current / maximum peak current a 10/15 10/15 16/25
Rated voltage / maximum switching voltage V AC 250/400 250/400 250/400
Rated load AC1 VA two thousand and five hundred two thousand and five hundred four thousand
Rated load ac15 (230 V AC) VA five hundred five hundred seven hundred and fifty
Single phase motor rating (230 V AC) kw
Breaking capacity dc1:30/110/220 V A 10/0.3/0.12 10/0.3/0.12 16/0.3/0.12
Minimum switching load MW (v/ma) 300(5/5) 300(5/5) 300(5/5)
Standard contact material AgNi AgNi AgNi
Coil specification
Nominal voltage (UN) V AC(50/60 Hz)

V DC



3 - 6 - 9 - 12 - 18 - 24 - 36 - 48

3 - 6 - 9 - 12 - 18 - 24 - 36 - 4

12 - 24 - 48
Rated power ac/dc VA (50 Hz) /w —/0.25 —/0.25 —/0.4
Operating range AC
DC (0.7…1.5)UN (0.7…1.5)UN (0.7…1.2)UN
Holding voltage ac/dc —/0.4 UN —/0.4 UN —/0.4 UN
Required voltage ac/dc —/0.05 UN —/0.05 UN —/0.05 UN
