| Specifications |
forty-one point three one | forty-one point five two | forty-one point six one | |
| Contact specifications | ||||
| Contact configuration | 1 CO (SPDT) | 2 CO (DPDT) | 1 CO (SPDT) | |
| Rated current / maximum peak current a | 12/25 | 8/15 | 16/30** | |
| Rated voltage / maximum switching voltage V AC | 250/400 | 250/400 | 250/400 | |
| Rated load AC1 VA | three thousand | two thousand | four thousand | |
| Rated load ac15 (230 V AC) VA | six hundred | four hundred | seven hundred and fifty | |
| Single phase motor rating (230 V AC) kw | zero point five | zero point three | zero point five | |
| Breaking capacity dc1:30/110/220 V A | 12/0.3/0.12 | 8/0.3/0.12 | 16/0.3/0.12 | |
| Minimum switching load MW (v/ma) | 300 (5/5) | 300 (5/5) | 300 (5/5) | |
| Standard contact material | AgNi | AgNi | AgNi | |
| Coil specification | ||||
| Nominal voltage (UN) | V AC(50/60 Hz) | 24 - 230 | 24 - 230 | 24 - 230 |
| V DC | 5 - 6 - 12 - 24 - 48 - 60 - 110 | 5 - 6 - 12 - 24 - 48 - 60 - 110 | 5 - 6 - 12 - 24 - 48 - 60 - 110 | |
| Rated power ac/dc VA (50 Hz) /w | 0.75/0.4 | 0.75/0.4 | 0.75/0.4 | |
| Operating range | AC | （0.8…1.1）UN | （0.8…1.1）UN | （0.8…1.1）UN |
| DC | （0.7…1.5）UN | （0.7…1.5）UN | （0.7…1.5）UN | |
| Holding voltage ac/dc | 0.8/0.4 UN | 0.8/0.4 UN | 0.8/0.4 UN | |
| Required voltage ac/dc | 0.15/0.1 UN | 0.15/0.1 UN | 0.15/0.1 UN | |
